4-Flute Unequal Long Neck Flat Bottom End Mill

1SMG024 series

category:

Difficult-to-machine materials flat bottom end mill

hotline:

0512-57488396

Contact

Details

Milling Cutters Made of Titanium Alloy, High Temperature Alloy, Carbon Steel, Alloy Steel and Other Difficult-to-Process Materials
Unique tool parameter design solves the problems of vibration, sticking, sharp wear and smooth chip removal.
The blade has high smoothness and improves the smoothness of processed materials.

Schematic Diagram

Blade Diameter Tolerance

Blade diameter tolerance
0.2 ≤ D ≤ 3	0~-0.01
3 ＜ D ≤ 12	0~-0.02
12 ＜ D	0~-0.03

Ordering Information

Order no	Basic size						Total number of teeth
Order no	Dia	Blade length	Neck diameter	Diameter length	Shank Diameter	Overall Length	Total number of teeth
1SMG024S-D4-6-d3.9- 16-D4-50	4.0	6	3.9	16	4	50.0	4.0
1SMG024S-D5-7.5-d4.9-20-D6-50	5.0	7.5	4.9	20	6	50.0	4.0
1SMG024S-D6-9-d5.9-24-D6-75	6.0	9	5.9	24	6	75.0	4.0
1SMG024S-D8- 12-d7.9-32-D8- 100	8.0	12	7.9	32	8	100.0	4.0
1SMG024S-D10- 15-d9.8-40-D10- 100	10.0	15	9.8	40	10	100.0	4.0
1SMG024S-D12- 18-d11.8-50-D12- 100	12.0	18	11.8	50	12	100.0	4.0
1SMG024S-D16-24-d15.8-50-D16- 150	16.0	24	15.8	50	16	150.0	4.0
1SMG024S-D18-27-d17.8-50-D18- 150	18.0	27	17.8	50	18	150.0	4.0
1SMG024S-D20-30-d19.8-60-D20- 150	20.0	30	19.8	60	20	150.0	4.0
